Stealth Pro Series

Variants:

STL PRO 1.5 Specifications

  • Motor Voltage: 120 VAC, 60 Hz
  • Energy Use: Hi: 323 Watts / Low: 274 Watts
  • Air Flow: Hi: 3216 CFM / Low: 2890 CFM
  • Recommended SQFT Coverage @2CFM per SQFT: Covers up to 1610 SQFT
  • Number of Speeds: 2
  • Duct Diameter: 16″
  • Duct Length: 6ft.
  • Motor Head Diameter: 16 1/2″
  • Motor Head Length: 13 1/2″
  • Dampers: Barometric Pressurized R5 Dampers
  • Controls: included 8 Hour Electronic Timer and HI-LOW-OFF Switch
  • Warranty: 15 years
  • Framing: None Required
  • Joist Cutting: None Required; fits 16″ or 24″ on center

TIPI PRO 1.5 Specifications

  • Motor Voltage: 120 VAC, 60 Hz
  • Energy Use: Hi: 323 Watts / Low: 274 Watts
  • Air Flow: Hi: 3216 CFM / Low: 2890 CFM
  • Recommended SQFT Coverage @2CFM per SQFT: Covers up to 1610 SQFT
  • Number of Speeds: 2
  • Duct Diameter: 16″
  • Duct Length: 6ft.
  • Motor Head Diameter: 16 1/2″
  • Motor Head Length: 13 1/2″
  • Dampers: Barometric Pressurized R5 Dampers
  • Controls: included 8 Hour Electronic Timer and HI-LOW-OFF Switch
  • Warranty: 15 years
  • Framing: None Required
  • Joist Cutting: None Required; fits 16″ or 24″ on center

TIPI PRO 1.5 Specifications

  • Motor Voltage: 120 VAC, 60 Hz
  • Energy Use: Hi: 323 Watts / Low: 274 Watts
  • Air Flow: Hi: 3216 CFM / Low: 2890 CFM
  • Recommended SQFT Coverage @2CFM per SQFT: Covers up to 1610 SQFT
  • Number of Speeds: 2
  • Duct Diameter: 16″
  • Duct Length: 6ft.
  • Motor Head Diameter: 16 1/2″
  • Motor Head Length: 13 1/2″
  • Dampers: Barometric Pressurized R5 Dampers
  • Controls: included 8 Hour Electronic Timer and HI-LOW-OFF Switch
  • Warranty: 15 years
  • Framing: None Required
  • Joist Cutting: None Required; fits 16″ or 24″ on center

TIPI PRO 1.5 Specifications

  • Motor Voltage: 120 VAC, 60 Hz
  • Energy Use: Hi: 323 Watts / Low: 274 Watts
  • Air Flow: Hi: 3216 CFM / Low: 2890 CFM
  • Recommended SQFT Coverage @2CFM per SQFT: Covers up to 1610 SQFT
  • Number of Speeds: 2
  • Duct Diameter: 16″
  • Duct Length: 6ft.
  • Motor Head Diameter: 16 1/2″
  • Motor Head Length: 13 1/2″
  • Dampers: Barometric Pressurized R5 Dampers
  • Controls: included 8 Hour Electronic Timer and HI-LOW-OFF Switch
  • Warranty: 15 years
  • Framing: None Required
  • Joist Cutting: None Required; fits 16″ or 24″ on center

TIPI PRO 1.5 Specifications

  • Motor Voltage: 120 VAC, 60 Hz
  • Energy Use: Hi: 323 Watts / Low: 274 Watts
  • Air Flow: Hi: 3216 CFM / Low: 2890 CFM
  • Recommended SQFT Coverage @2CFM per SQFT: Covers up to 1610 SQFT
  • Number of Speeds: 2
  • Duct Diameter: 16″
  • Duct Length: 6ft.
  • Motor Head Diameter: 16 1/2″
  • Motor Head Length: 13 1/2″
  • Dampers: Barometric Pressurized R5 Dampers
  • Controls: included 8 Hour Electronic Timer and HI-LOW-OFF Switch
  • Warranty: 15 years
  • Framing: None Required
  • Joist Cutting: None Required; fits 16″ or 24″ on center

TIPI PRO 1.5 Specifications

  • Motor Voltage: 120 VAC, 60 Hz
  • Energy Use: Hi: 323 Watts / Low: 274 Watts
  • Air Flow: Hi: 3216 CFM / Low: 2890 CFM
  • Recommended SQFT Coverage @2CFM per SQFT: Covers up to 1610 SQFT
  • Number of Speeds: 2
  • Duct Diameter: 16″
  • Duct Length: 6ft.
  • Motor Head Diameter: 16 1/2″
  • Motor Head Length: 13 1/2″
  • Dampers: Barometric Pressurized R5 Dampers
  • Controls: included 8 Hour Electronic Timer and HI-LOW-OFF Switch
  • Warranty: 15 years
  • Framing: None Required
  • Joist Cutting: None Required; fits 16″ or 24″ on center

TIPI PRO 1.5 Specifications

  • Motor Voltage: 120 VAC, 60 Hz
  • Energy Use: Hi: 323 Watts / Low: 274 Watts
  • Air Flow: Hi: 3216 CFM / Low: 2890 CFM
  • Recommended SQFT Coverage @2CFM per SQFT: Covers up to 1610 SQFT
  • Number of Speeds: 2
  • Duct Diameter: 16″
  • Duct Length: 6ft.
  • Motor Head Diameter: 16 1/2″
  • Motor Head Length: 13 1/2″
  • Dampers: Barometric Pressurized R5 Dampers
  • Controls: included 8 Hour Electronic Timer and HI-LOW-OFF Switch
  • Warranty: 15 years
  • Framing: None Required
  • Joist Cutting: None Required; fits 16″ or 24″ on center

Complete your Trident

R5 Damper Box with Removable Grille

Damper system features barometric pressurized gravity dampers that prevent heat/cooling loss between the home and attic. Traditional whole house fans that have older style shutters offer zero R-Value. The removable egg‐crate grille is very easy to remove and clean. During the colder months of the year, a homeowner can also apply the R40 Winterized Kit option to seal the damper box with R45 value.

Wall Controls and Timers

Every Trident Pro models include the standard manufacturer wall‐switch controls. This includes an Electronic 8‐Hour Countdown Timer and a single or multi-speed control switch (if applicable). Be sure to reach out to us if you have any questions about switches and timers for whole house fans.
